Hirth Engines – 32 Series

Hirth

Ideally suited for light and ultralight aviation. The 32 Series air cooled two-stroke engines offer the highest power-to-weight ratios available in the 55-horsepower market.

Ideally suited for use in light and ultralight aviation, hovercraft, gyro and helicopters and all applications where weight could be an issue. The most powerful air cooled 2-stroke engine we’ve developed, the 32 Series offers a time between overhauls of over 1000 hours.

3203 – 32 Series

  • Brand: HIRTH ENGINES
  • Performance: 55 HP / 40.4 kW @ 5500 rpm
  • Type: Air Cooled, 2-Stroke, Two cylinder inline
  • Ratio: Ultimate power to weight ratio
  • Application: Ideal for light aviation, hovercraft, gyro or helicopters

TECHNICAL SPECIFICATION

  • Displacement: 625 cm³ (38.1 in³)
  • Stroke / Bore: 69 mm / 76 mm
  • Max. Torque: 72 Nm @ 5000 rpm
  • Carburation: 2x slide carburetor (Dell Orto) or fuel injection
  • Fuel Mixture: Mixture 1:50, 2-stroke-oil, min. 95 octane
  • Weight: 31 kg (68.4 lb)
